The XL Omega is the largest production CleanStation available.

With a work envelope in excess of 33,000 cubic inches, the 140-gallon tank features a 360-degree, multi-jet manifold powered by a 53-gallon-per-minute stainless steel pump to clean parts fast. Unlike ultrasonic cleaners, CleanStation systems are not load sensitive, offering efficient batch processing for maximum throughput. The XL Omega features a fully-programmable microprocessor-controlled circulation heater combined with an active cooling system to maintain optimal operating temperature. Options: Automated Lift System For use with all FDM/FFF 3-D printers with soluble support.

Product Features

  • Large part capacity
  • Heavy duty, industrial grade
  • Stainless steel tank and basket
  • “One touch” automated control
  • Programmable for time and temperature
  • Quick warm up
  • 360-degree multi-jet manifold
  • Locking casters



  • Stainless steel ‘hose barb’ plumbing inlets and outlet
  • Hinged and locking tank lid
  • Large-capacity stainless steel parts basket
  • Adjustable flow rate
  • Recessed “no drip” top
  • One-year warranty
  • Made in USA

Product Specifications

  • Work envelope: 36 x 37 x 26
  • Machine Dimensions: 74.5 x 51 x 38
  • Power Requirements: 3-phase, 240 VAC, 70 AMP
  • Shipping weight: 1,800 lbs.
