The XL Omega is the largest production CleanStation available.

With a work envelope in excess of 33,000 cubic inches, the 140-gallon tank features a 360-degree, multi-jet manifold powered by a 53-gallon-per-minute stainless steel pump to clean parts fast. Unlike ultrasonic cleaners, CleanStation systems are not load sensitive, offering efficient batch processing for maximum throughput.

The XL Omega features a fully-programmable microprocessor-controlled circulation heater combined with an active cooling system to maintain optimal operating temperature.

Options: Automated Lift System

For use with all FDM/FFF 3-D printers with
soluble support.

Product Features

  • Large part capacity
  • Heavy duty, industrial grade
  • Stainless steel tank and basket
  • “One touch” automated control
  • Programmable for time and temperature
  • Quick warm up
  • 360-degree multi-jet manifold
  • Locking casters



  • Stainless steel ‘hose barb’ plumbing inlets and outlet
  • Hinged and locking tank lid
  • Large-capacity stainless steel parts basket
  • Adjustable flow rate
  • Recessed “no drip” top
  • One-year warranty
  • Made in USA

Product Specifications

  • Work envelope: 37” x 36.50” x 26.13”
  • Machine Dimensions: 74.58” x 51” x 37.85”
  • Power Requirements: 51 Amps (* 208 VAC)
  • Tank capacity: 35,288 cubic-inch, 150-gallon
    stainless steel tank
  • Shipping weight: 1,800 lbs.
